Mid size connectors (4.3-10, C, N, UHF)

HUBER+SUHNER connector series 4.3-10, N, UHF and C are mainly used for connections with a cable assembly to a panel. The different connector series offer a wide range of products suitable for various applications (indoor and outdoor).

4.3-10

4.3-10

HUBER+SUHNER 4.3-10 connectors offer very low PIM performance together with weight and compactness advantages. A key feature of this connector is the separation of the electrical and mechanical plane, which results in a lower coupling torque and the possiblility of offering the connector with screw, hand-screw and quick-lock design, thus simplifying the installation effort and offering for all mechanisms a very high and reliable electrical performance independently from the torque applied.

4.3-10 Plus

4.3-10 Plus

The 4.3-10 Plus interface is for applications which carry risk of a Mini Din/4.1-9.5 male connector accidently mating with a 4.3-10 female interface. 4.3-10 Plus interface is based on the standard IEC 4.3-10 specification but with a slight modification of dielectric inside the outer conductor which makes the 4.3-10 Plus interface more robust and fully prevents the male Mini Din/ 4.1-9.5 connector from entering and damaging the 4.3-10 female. The 4.3-10 Plus female connectors are are fully compatible with all standard 4.3-10 male connectors.

C

C

HUBER+SUHNER C connectors are medium size RF connectors with two-stud bayonet mechanism which allows quick and easy coupling and decoupling. The C connectors provide 50 ohm impedance and the frequency range (connector interface) is specified for applications up to 11 GHz.

N 50 Ω / N 75 Ω

N 50 Ω / N 75 Ω

HUBER+SUHNER N connectors are available with 50 ohm and 75 ohm impedance. The frequency range extends to 18 GHz, depending on the connector and cable type. The screw-type coupling mechanism provides a sturdy and reliable connection. HUBER+SUHNER N connectors are available for flexible cables, for semi-rigid cables and for corrugated copper tube cables. Cable entries: clamp, crimp and solder types available, as well as HUBER+SUHNER Quick-Fit for corrugated copper tube cables.

UHF

UHF

UHF connectors do not have defined impedance. They are intended for applications up to 200 MHz where mechanically robust connectors are required. They are mateable with 4 mm banana plugs.
