Corrugated, 50 Ohm, 18 GHz, 85°C, ø7.6 mm, LSFH jacket

Product number 84020855

Identifier SUCOFEED_1/4_HF_FR

Variation -

General Information

Key features

Low loss, low IM distortion levels
High power capability
Flame retardant designs available
High shieding effectiveness

Specifications

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Copper clad Aluminum	Wire	1.9 mm
Dielectric	SPE (Foamed Polyethylene)		4.6 mm
Outer conductor	Copper	Tube, corrugated, 100%	6.4 mm
Jacket	LSFH (modified polyethylene)	RAL 9011 - graphite black	7.6 mm +/- 0.4 mm	HUBER+SUHNER_SUCOFEED_1/4_HF_FR_#batch-number#_#metric-length#

Electrical data

Mechanical data

Environmental data

Material compliance ROHS

Material compliance REACH

Corrugated, 50 Ohm, 18 GHz, 85°C, ø7.6 mm, LSFH jacket

Related products

Suitable connectors

COAXIAL CONNECTOR, 7/16, 50 Ohm, Right angle cable plug (male)

COAXIAL CONNECTOR, 7/16, 50 Ohm, Right angle cable plug (male)

23016774

16_716-50-5-2/003_-Z

Bulk packaging

COAXIAL CONNECTOR, 7/16, 50 Ohm, Straight cable plug (male)

COAXIAL CONNECTOR, 7/16, 50 Ohm, Straight cable plug (male)

23003412

11_716-50-5-4/003_-Z

Bulk packaging

COAXIAL CONNECTOR, N, 50 Ohm, Straight cable plug (male)

COAXIAL CONNECTOR, N, 50 Ohm, Straight cable plug (male)

23011948

11_N-50-5-400/103_UY

Bulk packaging

COAXIAL CONNECTOR, QN, 50 Ohm, Straight cable plug (male)

84022712

11_QN-50-5-2/133_NH

Bulk packaging
