Field mountable, 50 Ohm, 18 GHz, 200°C, ø7.7 mm, FEP jacket
Product number 84116403
Identifier EACON_6C
Variation -
General Information
Product code |
|
Cable family |
|
Available as assembly only |
|
Cable group |
|
- Field mountable microwave cable designed for assembly in tight spaces
- Excellent performance up to 18 GHz
- 2 piece solderless connectors for easy assembly and re-assembly in the field
- Waterproof IP67 rated
Key features
Specifications
Component | Material | Detail | Diameter | Cable jacket print |
---|---|---|---|---|
Centre conductor | Copper, Silver plated | Wire | 2.05 mm | |
Dielectric | PTFE-LD | 6.2 mm | ||
Outer conductor | Copper, Silver plated | Wrapped foil, 100% | 6.42 mm | |
Outer conductor | Copper, Silver plated | Braid | 7.1 mm | |
Jacket | FEP (Fluorinated ethylene propylene) | White | 7.7 mm | HUBER+SUHNER EACON 6C 50 OHM (PA Nr.) |
Impedance |
|
Operating frequency |
|
Capacitance |
|
Velocity of signal propagation |
|
Signal delay |
|
Screening effectiveness |
|
Operating Voltage (at sea level) |
|
Weight |
|
Static bending radius |
|
Dynamic bending radius |
|
Operation temperature |
|
Flame propagation standard |
|
Fire characteristics |
|
Directive |
|
Rating |
|
Regulation |
|
Rating |
|
