50 Ohm, 6 GHz, 85°C, ø10.8 mm, LSFH jacket

Product number 22512085

Identifier G_07262_D

Variation -

General Information

Key features

Custom version of standard RG cable
Suitable for use in applications up to 6 GHz
Low smoke

Specifications

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Copper, Silver plated	Strand-07, 93%	2.25 mm - 0.15 mm
Dielectric	PE (Polyethylene)		7.28 mm
Outer conductor	Copper, Silver plated	Braid, 93%	8 mm
Outer conductor	Copper, Silver plated	Braid, 95%	8.7 mm
Jacket	LSFH (modified polyethylene)	RAL 9005 - bk	10.8 mm +/- 0.15 mm	HUBER+SUHNER G 07262 D 50 Ohm (production order number)

Electrical data

Impedance	50 Ω +/-1Ω
Operating frequency	≤ 6 GHz
Capacitance	101 pF/m
Velocity of signal propagation	66 %
Signal delay	5.03 ns/m
Screening effectiveness	80 dB at frequency 0.001 GHz ... 1GHz
Insulation resistance	100000000 MΩ*m
Inner conductor resistance	5.8 Ω/km
Outer conductor resistance	3.9 Ω/km
Operating Voltage (at sea level)	≤ 5 kVrms
Phase vs temperature	-40 ... 70 °C
Phaase vs bending	9 °/GHz
Test voltage (50 Hz/1 min)	≤ 10 kVrms

Mechanical data

Environmental data
