Corrugated, 50 Ohm, 8.8 GHz, 85°C, ø15.9 mm, LSFH jacket

Product number 84020848

Identifier SUCOFEED_1/2_FR

Variation -

General Information

Key features

Low loss, low IM distortion levels
High power capability
High shieding effectiveness
Flame retardant designs available

Specifications

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Copper clad Aluminum	Wire	4.8 mm
Dielectric	SPE (Foamed Polyethylene)		12.1 mm
Outer conductor	Copper	Tube, corrugated, 100%	13.8 mm
Jacket	LSFH (modified polyethylene)	RAL 9011 - graphite black	15.9 mm +/- 0.4 mm	HUBER+SUHNER_SUCOFEED_1/2_FR_#batch-number#_#metric-length#

Electrical data

Mechanical data

Environmental data

Material compliance ROHS

Material compliance REACH

Corrugated, 50 Ohm, 8.8 GHz, 85°C, ø15.9 mm, LSFH jacket

Related products

Suitable connectors

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Right angle cable plug (male)

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Right angle cable plug (male)

85067267

16_4310-50-12-X60/033_-E

Single packaging

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Right angle cable plug (male)

85074830

16_4310-50-12-Z60/033_-E

Single packaging

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Right angle cable plug (male)

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Right angle cable plug (male)

85080030

16_4310-50-12-X1/033_-E

Single packaging

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Straight cable jack (female)

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Straight cable jack (female)

85029736

21_4310-50-12-1/033_-E

Single packaging

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Straight cable jack (female)

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Straight cable jack (female)

85067226

21_4310-50-12-60/033_-E

Single packaging

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Straight cable plug (male)

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Straight cable plug (male)

85020537

11_4310-50-12-X2/033_-E

Single packaging

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Straight cable plug (male)

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Straight cable plug (male)

85021551

11_4310-50-12-Y2/033_-E

Single packaging

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Straight cable plug (male)

85021552

11_4310-50-12-Z2/033_-E

Single packaging

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Straight cable plug (male)

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Straight cable plug (male)

85067026

11_4310-50-12-X60/033_-E

Single packaging

COAXIAL CONNECTOR, 4.3-10, 50 Ohm, Straight cable plug (male)

85074839

11_4310-50-12-Y60/033_-E

Single packaging

COAXIAL CONNECTOR, 7/16, 50 Ohm, Right angle cable plug (male)

COAXIAL CONNECTOR, 7/16, 50 Ohm, Right angle cable plug (male)

84201179

16_716-50-12-50/033_-E

Single packaging

COAXIAL CONNECTOR, 7/16, 50 Ohm, Right angle cable plug (male)

COAXIAL CONNECTOR, 7/16, 50 Ohm, Right angle cable plug (male)

85074821

16_716-50-12-60/033_-E

Single packaging

COAXIAL CONNECTOR, 7/16, 50 Ohm, Straight cable jack (female)

COAXIAL CONNECTOR, 7/16, 50 Ohm, Straight cable jack (female)

84201177

21_716-50-12-50/033_-E

Single packaging

COAXIAL CONNECTOR, 7/16, 50 Ohm, Straight cable jack (female)

COAXIAL CONNECTOR, 7/16, 50 Ohm, Straight cable jack (female)

85074832

21_716-50-12-60/033_-E

Single packaging

COAXIAL CONNECTOR, 7/16, 50 Ohm, Straight cable plug (male)

COAXIAL CONNECTOR, 7/16, 50 Ohm, Straight cable plug (male)

84201175

11_716-50-12-50/033_-E

Single packaging

COAXIAL CONNECTOR, 7/16, 50 Ohm, Straight cable plug (male)

COAXIAL CONNECTOR, 7/16, 50 Ohm, Straight cable plug (male)

85074815

11_716-50-12-60/033_-E

Single packaging

COAXIAL CONNECTOR, N, 50 Ohm, Right angle cable plug (male)

COAXIAL CONNECTOR, N, 50 Ohm, Right angle cable plug (male)

84201181

16_N-50-12-50/033_-E

Single packaging

COAXIAL CONNECTOR, N, 50 Ohm, Right angle cable plug (male)

COAXIAL CONNECTOR, N, 50 Ohm, Right angle cable plug (male)

85074824

16_N-50-12-60/033_-E

Single packaging

COAXIAL CONNECTOR, N, 50 Ohm, Straight cable jack (female)

COAXIAL CONNECTOR, N, 50 Ohm, Straight cable jack (female)

84201173

21_N-50-12-50/033_-E

Single packaging

COAXIAL CONNECTOR, N, 50 Ohm, Straight cable jack (female)

COAXIAL CONNECTOR, N, 50 Ohm, Straight cable jack (female)

85074835

21_N-50-12-60/033_-E

Single packaging

COAXIAL CONNECTOR, N, 50 Ohm, Straight cable plug (male)

COAXIAL CONNECTOR, N, 50 Ohm, Straight cable plug (male)

84201169

11_N-50-12-50/033_-E

Single packaging

COAXIAL CONNECTOR, N, 50 Ohm, Straight cable plug (male)

COAXIAL CONNECTOR, N, 50 Ohm, Straight cable plug (male)

85074817

11_N-50-12-60/033_-E

Single packaging

COAXIAL CONNECTOR, SMA, 50 Ohm, Straight cable plug (male)

COAXIAL CONNECTOR, SMA, 50 Ohm, Straight cable plug (male)

85015025

11_SMA-50-4-74/199_NI

Bulk packaging
