RG316, 50 Ohm, 3 GHz, 200°C, ø2.5 mm, FEP jacket
RG316, 50 Ohm, 3 GHz, 200°C, ø2.5 mm, FEP jacket
-
Product code
RG_316_/U
Cable family
RG: RG type RF cables
Available as assembly only
No
Cable group
U2
U2
Mil standard RG cable
Excellent RF performance for precision applications
Suitable for use in applications up to 3 GHz
Extended temperature range
Construction
Component
Material
Detail
Diameter
Centre conductor
Steel, Copper + Silver plated
Strand-07
0.54 mm
Dielectric
PTFE (Polytetrafluoroethylene)
1.55 mm
Outer conductor
Copper, Silver plated
Braid, 95%
2 mm
Jacket
FEP (Fluorinated ethylene propylene)
RAL 8015 - br
2.5 mm +/- 0.1 mm
Electrical data
Impedance
50 Ω +/-2Ω
Operating frequency
≤ 3
GHz
Capacitance
97
pF/m
Velocity of signal propagation
69
%
Signal delay
4.86
ns/m
Screening effectiveness
38 dB at frequency 0.0001 GHz ... 1GHz
Insulation resistance
100000000
MΩ*m
Inner conductor resistance
235
Ω/km
Operating Voltage (at sea level)
≤ 1.5
kVrms
Test voltage (50 Hz/1 min)
≤ 3
kVrms
Mechanical data
Weight
approx. 16
g/m
Static bending radius
≥ 15
mm
Repeated bending radius
25 mm
Dynamic bending radius
< 37.5
mm
Environmental data
Operation temperature
-65 °C ... 200 °C
Installation temperature
-20 °C ... 60 °C
Flame propagation standard
IEC 60332-3
Fire characteristics
contains halogene
