RG142 LSFH, 50 Ohm, 6 GHz, 105°C, ø5 mm, RADOX® jacket

Product number 22512168

Identifier ENVIROFLEX_142

Variation -

General Information

Key features

Halogen free alternative to RG cables
Low smoke
Ozone, UV and weathering resistance
UL AWM style 3651

Specifications

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Copper, Silver plated	Wire	0.95 mm
Dielectric	SPEX (Crosslink Foam PE)		2.95 mm
Outer conductor	Copper, Silver plated	Braid, 97%	3.58 mm
Outer conductor	Copper, Silver plated	Braid, 95%	4.16 mm
Jacket	RADOX	black/bl line	5 mm +/- 0.1 mm	HUBER+SUHNER ENVIROFLEX 142 50 Ohm (UL logo) AWM Style 3651 (production order number)

Electrical data

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 6 GHz
Capacitance	94.5 pF/m
Velocity of signal propagation	70.9 %
Signal delay	4.7 ns/m
Screening effectiveness	75 dB at frequency 5GHz
Insulation resistance	10000000 MΩ*m
Inner conductor resistance	23.655 Ω/km
Inner conductor DC resistance at 300K	9.5 Ω/km
Outer conductor resistance	9.5 Ω/km
Outer conductor DC resistance at 300K	300 V
Operating Voltage (at sea level)	≤ 2.5 kVrms
Voltage Rating UL	300 V
Phase vs temperature	9000 ppm within the temperature range -40 ... 100 °C
Test voltage (50 Hz/1 min)	≤ 5 kVrms

Mechanical data

Environmental data

Operation temperature	-40 °C ... 105 °C
Installation temperature	-20 °C ... 60 °C
Flame propagation standard	IEC 60332-1-2 UL 1581 § 1100 IEC 60332-2 EN 50305, 9.1.2
Fire characteristics	free of halogenes, acc. standard IEC 60754
Smoke test	EN 61034-2
Ageing test	MIL-C-17 § 4.8.16
Cold bend test	MIL-C-17 § 4.8.19
UV resistance	IEC 60068-2-5, proc. C
Thermal stress test	IEC 61196-1 § 10.9

Material compliance ROHS

RG142 LSFH, 50 Ohm, 6 GHz, 105°C, ø5 mm, RADOX® jacket

Availabilities

This product is available at:

HUBER+SUHNER

Lead time 4 weeks (ex works)

Distributor

FC LANE 1100 Meter

FARNELL with lead time

RS COMP. with lead time

RICHARDSON RFPD with lead time

MOUSER 854 Meter

DIGIKEY 130 Meter

MASTER ELECTR. 276 Meter

Product code	ENVIROFLEX_142
Cable family	Enviroflex: LSFH alternatives to RG cables
Available as assembly only	No
Cable group	U9

Weight	approx. 60 g/m
Static bending radius	≥ 30 mm
Repeated bending radius	50 mm
Dynamic bending radius	< 30 mm
Abrasion test	MIL-T-81490 - §4.7.19 - prod. II - modified

Directive	RoHS 2011/65/EU and (EU) 2015/863
Rating	Compliant without exemption
