RG178 LSFH, 50 Ohm, 3 GHz, 105°C, ø1.84 mm, RADOX® jacket

Product number 23010656

Identifier ENVIROFLEX_178

Variation -

General Information

Key features

Halogen free alternative to RG cables
Low smoke
Ozone, UV and weathering resistance
UL AWM style 3651

Specifications

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Steel, Copper + Silver plated	Strand-07	0.305 mm
Dielectric	SPEX (Crosslink Foam PE)		0.82 mm
Outer conductor	Copper, Silver plated	Braid, 95%	1.27 mm
Jacket	RADOX	RAL 5010 - bl	1.84 mm +/- 0.07 mm	HUBER+SUHNER ENVIROFLEX 178 50 Ohm (UL logo) AWM Style 3651 (production order number)

Electrical data

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 3 GHz
Capacitance	94.5 pF/m
Velocity of signal propagation	70.7 %
Signal delay	4.71 ns/m
Screening effectiveness	40 dB at frequency 0.03 GHz ... 3GHz
Insulation resistance	10000000 MΩ*m
Inner conductor resistance	747 Ω/km
Inner conductor DC resistance at 300K	50 Ω/km
Outer conductor resistance	50 Ω/km
Outer conductor DC resistance at 300K	300 V
Operating Voltage (at sea level)	≤ 1 kVrms
Voltage Rating UL	300 V
Phase vs temperature	8400 ppm within the temperature range -40 ... 100 °C
Phaase vs bending	0.7 °/GHz
Test voltage (50 Hz/1 min)	≤ 2 kVrms

Mechanical data

Environmental data

Material compliance ROHS

RG178 LSFH, 50 Ohm, 3 GHz, 105°C, ø1.84 mm, RADOX® jacket

Availabilities

This product is available at:

HUBER+SUHNER

Lead time 6 weeks (ex works)

Distributor

FARNELL 4 Meter

RS COMP. 100 Meter

RICHARDSON RFPD with lead time

MOUSER 862 Meter

DIGIKEY 981 Meter

MASTER ELECTR. 315 Meter

Product code	ENVIROFLEX_178
Cable family	Enviroflex: LSFH alternatives to RG cables
Available as assembly only	No
Cable group	U1

Weight	approx. 6.5 g/m
Static bending radius	≥ 5 mm
Repeated bending radius	20 mm
Dynamic bending radius	< 30 mm

Operation temperature	-40 °C ... 105 °C
Installation temperature	-20 °C ... 60 °C
Flame propagation standard	UL 1581 § 1100
Fire characteristics	free of halogenes, acc. standard IEC 60754
Ageing test	MIL-C-17 § 4.8.16
Cold bend test	MIL-C-17 § 4.8.19
UV resistance	IEC 60068-2-5, proc. C
Solar radiation	IEC 60068-2-5, proc. C

Directive	RoHS 2011/65/EU and (EU) 2015/863
Rating	Compliant without exemption
